BN-5668 made in JAPAN
Order model number
- Order model numberBN-5668-[Voltage]-[Lens color]
- Order exampleBN-5668-1-R (An example of ordering with a red lens with a voltage of AC100-125V.)
- BN-5668-2-R (An example of ordering with a red lens with a voltage of AC200-250V.)
Lens color
-
R
-
G
-
OR
-
C
*The lighting color of the lens color C is orange.
Basic information
| Rating | AC100V～125V、AC200V～250V |
|---|---|
| Insulation resistance | DC500V、100MΩ Min |
| Withstand voltage | AC1500V (1minute) |
| Life | 20000 hours Min (Serial lighting) |
| Body material | Polycarbonate |
| How to mount | With nut |
| Main insulator | PBT (UL94V-0) |
| Terminal type | Soldering |
| Lens color | R (Red)、G (Green)、OR (Orange)、C (Clear) |
| Panel thickness | 8.0mm (MAX) |
| Nut torque | 0.7N･m |
| Caution | 1.When soldering, please solder with the lug facing down or horizontal. |
